ATWOOD HYDRAULIC BRAKE ACTUATOR. ATWOOD HYDRAULIC BRAKE ACTUATOR REPLACEMENT KITS (These Brake Actuator Replacement Kits are coming soon to our site, please order by phone until further notice. Customer Service hours are Monday thru Friday 8 am - 5 pm PST. Toll Free: (877) 367-4236)

ALL OTHER Atwood couplers are fine (80xxx, 81xxx, 82xxx, etc). Although we have some customers who are using the 88xxx series without problem, for the best solution our official stand is this - if you have one, change out your coupler. Luckily it is not a common coupler, but it is popular on Airstream trailers. Below is our official announcement:

The Atwood Power Jack is a 12-volt DC motor driven screw jack intended for use on recreational type and marine trailers. Patent # D349800. Jack is used to level trailer or raise and lower coupler for hookup to tow vehicle. CAUTION PERSONAL INJURY/PROPERTY DAMAGE • Retract jack fully before towing. • Do not use blocks to increase height of jack.

Atwood trailer coupler diagram

Atwood trailer coupler diagram

Periodically oil pivot points and sliding surfaces of coupler with SAE 30 wt. Motor oil. When parking or storing your trailer keep the coupler off the ground so dirt will not build up in the ball socket. II. COUPLER INSTALLATION/WELDING DIAGRAMS: INSTALLATION INSTRUCTIONS FOR CLASS-1 COUPLERS. Use 1/8" Fillet Weld as shown below.

1. Block tires of trailer and securely support trailer tongue. 2. The Atwood RV Power Jack is designed to attach to the top surface of an A-frame type tongue having mounting holes typical of the Atwood A-frame couplers FIG 1. Use coupler installation instructions (MPD 87984) if installing coupler. The Marine Power Jack attaches to the side
